5kw Victron Energy Inverter 48v

⚡ Victron Energy 5kW Inverter | 48V | Pure Sine Wave | High-Efficiency | Hybrid Solar Inverter

Brand: Victron Energy
Model: MultiPlus 5kW 48V
Rated Power: 5,000W (5kW)
System Voltage: 48V
Phase: Single Phase
Warranty: 5-Year Manufacturer Warranty (Extendable)
Availability: In Stock

🔋 Reliable & Efficient Power Solution for Residential & Small Commercial Systems

The Victron Energy 5kW Inverter 48V is a top-of-the-line hybrid inverter designed for residential and small commercial solar systems. Featuring pure sine wave output, MPPT charging capabilities, and 48V battery compatibility, this inverter delivers highly efficient power management. Whether you need a grid-tied or off-gridsolution, the Victron Energy MultiPlus ensures uninterrupted, reliable power for your home or business.

✅ Key Features:

• ✔️ 5,000W (5kW) Pure Sine Wave Output – Ideal for homes, small businesses, and backup power applications

• ☀️ MPPT Solar Charging – Efficiently manages and maximizes energy production from your solar panels

• 🔋 48V Battery Compatibility – Supports lithium-ion, AGM, and gel batteries for reliable energy storage

• 🔄 Grid-Tie & Off-Grid Ready – Perfect for both grid-connected and independent off-grid systems

• 📱 Advanced Monitoring – Remote monitoring via Victron’s VE.Direct or Bluetooth for easy performance tracking

• 🛡️ Built-in Protection – Surge, overload, and short-circuit protection for enhanced system safety

• 💡 Seamless Backup Power – Automatically switches to battery power in case of grid failure to ensure continuous power supply

🌞 Solar PV Input:

• Max Solar Power Input: 6,000W

• MPPT Voltage Range: 120V – 400VDC

• Max PV Voltage: 450VDC

• Number of MPPTs: 1

• Max Input Current per MPPT: 12A

⚡ AC Output (Single Phase):

• Rated Output Power: 5,000W

• Output Voltage: 230VAC

• Frequency: 50/60Hz (Auto-detect)

• Surge Power: Up to 7,500W

• Power Factor: >0.99

• Max Efficiency: 96%

🔋 Battery Compatibility:

• Battery Voltage Range: 48VDC

• Max Charge/Discharge Current: 100A

• Supported Battery Types:

  • Lithium-ion (via BMS)

  • AGM / GEL (Lead-Acid)

• Programmable Charge/Discharge Settings

📐 Product Specifications:

• Dimensions: 350mm (W) x 210mm (H) x 130mm (D)

• Weight: Approx. 15 kg

• Cooling Method: Intelligent Fan Cooling

• Protection Rating: IP21 (Indoor use only)

• Operating Temperature: -20°C to 60°C

• Communication Ports: VE.Direct, Bluetooth (Optional), CAN-bus

📦 What’s in the Box?

• 1 × Victron Energy 5kW Inverter

• 1 × User Manual & Quick Start Guide

• 1 × Remote Monitoring Cable

• 1 × VE.Direct Cable (optional Bluetooth dongle available separately)

🏠 Perfect For:

• Residential Solar Power Systems

• Small Commercial Solar Installations

• Backup Power Solutions

• Off-Grid Solar Power Systems

• Grid-Tied Solar Systems

• Flexible Energy Storage Solutions
