Sunsynk 8kW 48V Single Phase Hybrid Inverter

⚡ Sunsynk 8kW Hybrid Inverter | 48V | MPPT | Pure Sine Wave | Grid-Tie & Off-Grid Ready

🔋 Efficient and Reliable Hybrid Energy Solution for Residential & Commercial Systems

The Sunsynk 8kW 48V Single Phase Hybrid Inverter is designed for medium to large residential and small commercial solar power applications. With MPPT technology, 48V battery compatibility, and pure sine wave output, this inverter ensures optimal energy production and efficient battery storage. It offers the flexibility to operate in both grid-tied and off-grid modes, providing reliable backup power while maximizing solar energy use.

✅ Key Features:

• ✔️ 8,000W Pure Sine Wave Output – Perfect for homes, small businesses, and backup energy applications

• ☀️ MPPT Technology – Maximizes solar energy conversion by tracking optimal sunlight conditions, boosting system efficiency

• 🔋 48V Battery Compatibility – Works with lithium-ion, AGM, and gel batteries for flexible energy storage

• 🔄 Grid-Tie & Off-Grid Ready – Easily integrates with the grid or operates independently in off-grid systems

• 📱 Wi-Fi Monitoring – Track system performance via mobile app or web portal for real-time data and insights

• 🛡️ Comprehensive Protection – Includes overload, short-circuit, over-voltage, and temperature protection for long-lasting durability

• 💡 Batteryless Operation – Operates as a grid-tied inverter without needing batteries for easy and cost-effective installations

🌞 Solar PV Input:

• Max PV Input Power: 10,000W

• Max PV Voltage: 550VDC

• MPPT Operating Range: 150V – 500VDC

• Number of MPPTs: 1

• Max Input Current per MPPT: 13A

⚡ AC Output (Single Phase):

• Rated Output Power: 8,000W

• Output Voltage: 230VAC

• Frequency: 50/60Hz (Auto-detect)

• Surge Power: Up to 12,000W

• Power Factor: >0.99

• Max Efficiency: 97%

🔋 Battery Compatibility:

• Battery Voltage Range: 48VDC

• Max Charge/Discharge Current: 100A

• Supported Battery Types:

  • Lithium-ion (via RS485 BMS)

  • AGM / GEL (Lead-Acid)

• Programmable Charge/Discharge Modes

📐 Product Specifications:

• Dimensions: 500mm (W) x 370mm (H) x 180mm (D)

• Weight: Approx. 22 kg

• Cooling Method: Intelligent Fan Cooling

• Protection Rating: IP65 (Suitable for both indoor and outdoor installations)

• Operating Temperature: -25°C to 60°C

• Communication Ports: Wi-Fi, RS485, USB

📦 What’s in the Box?

• 1 × Sunsynk 8kW Hybrid Inverter

• 1 × Wi-Fi Monitoring Dongle

• 1 × Wall Mount Kit

• 1 × User Manual & Quick Start Guide

🏠 Perfect For:

• Residential Solar Power Systems

• Small Business Solar Installations

• Backup Power Solutions

• Off-Grid Solar Systems

• Grid-Tied Solar Systems

• Energy Storage Solutions

📣 Installers & Distributors – Get Exclusive Trade Pricing!

Are you a certified solar installer or distributor? Contact us for special B2B pricing and support!
👉 Partner with Sunsynk and boost your solar business with exclusive offers, training, and resources.
