CNBM 10M-330 330W Mono Solar Panel

The CNBM 10M-330 330W Mono Solar Panel is a high-performance monocrystalline module designed for both residential and commercial solar power systems. Its efficient design ensures reliable energy production, making it ideal for on-grid or off-grid installations.

High Efficiency Solar Performance

With a rated output of 330W, the CNBM Mono Solar Panel delivers strong energy performance even in low-light conditions. The panel uses high-quality monocrystalline cells for maximum conversion efficiency and consistent power generation.

Durable and Weather-Resistant Design

The CNBM Mono Solar Panel is built to last with tough tempered glass, an anodized aluminum frame, and IP67/IP68-rated junction box. Certified to withstand high wind loads (2400 Pa) and snow loads (5400 Pa), it’s ideal for all weather conditions.

Technical Specifications

• Maximum Power (Pmax): 330 W

• Module Efficiency: 21.8%

• Open Circuit Voltage (Voc): 39.5 V

• Voltage at Pmax (Vmp): 33.8 V

• Short Circuit Current (Isc): 10.1 A

• Current at Pmax (Imp): 9.76 A

• Power Tolerance: 0 ~ +5 W

• Cell Type: Monocrystalline

• Number of Cells: 60

• Dimensions: 1956 × 992 × 35 mm

• Weight: 19.5 kg

• Frame: Anodized Aluminum Alloy

• Glass: 3.2 mm tempered glass

• Connector: MC4 compatible

• Operating Temperature: -45°C to +80°C

Reliable Warranty

The CNBM 10M-330 330W  comes with a 10-year product warranty and a 25-year linear power output warranty, ensuring long-term performance and durability.
